Bearing Kappa Factor Calculator

Content

Calculate the ISO 281 bearing kappa factor from lubricant operating-temperature viscosity and the reference viscosity for the bearing size and speed condition.

Calculate kappa

Use viscosity at the actual bearing operating temperature. ISO VG grade alone is not enough when the bearing runs hotter or colder than the datasheet reference temperature.

How to use

  1. Enter the lubricant Operating viscosity, ν, at the actual bearing operating temperature in cSt (mm²/s).
  2. Enter the Reference viscosity, ν₁, in the same units. Obtain ν₁ from validated bearing size-and-speed guidance or an ISO 281 workflow.
  3. Enter a positive dimensionless Target kappa to estimate the required operating-temperature viscosity. There is one calculation mode; all three inputs must be greater than zero.
  4. The calculator updates automatically as you type—this is the Calculate behavior. Select Reset to restore the example values 22 cSt, 10 cSt, and target κ = 4.
  5. Read the kappa factor, assessment, practical κ = 1 to 4 viscosity band, and selected target viscosity in the single Result panel. Correct any warning before using the output.
  6. Do not use this screening ratio by itself for bearing-life prediction or lubricant approval. Check operating temperature, load, speed, contamination, grease behavior, additive chemistry, manufacturer limits, and transient duty separately.

Equations used

The calculator uses the ISO 281 viscosity-ratio definition and three directly derived screening quantities:

Falex
κ = ν / ν₁

Bearing kappa factor, dimensionless.

νtarget = κtarget × ν₁

Operating-temperature kinematic viscosity needed for the selected target kappa, in cSt (mm²/s).

νmin = ν₁

Lower edge of the practical screening band at κ = 1, in cSt (mm²/s).

νupper = 4 × ν₁

Upper edge of the displayed practical screening band at κ = 4, in cSt (mm²/s).

Rheologylab

Symbols: κ is the dimensionless viscosity ratio; ν is lubricant kinematic viscosity at the bearing operating temperature; ν₁ is the reference kinematic viscosity for the bearing size and speed condition; κtarget is the selected positive target ratio. ν, ν₁, νtarget, νmin, and νupper must use the same units. Kinematic viscosity is positive, so every user input must be greater than zero.

Interpretation and limits: κ < 1 is below the reference viscosity; 1 ≤ κ ≤ 4 is displayed as the practical screening zone; κ > 4 is above that common zone and may increase drag or heat. These thresholds are screening guidance, not a complete bearing-life or lubricant-selection model.

Reference: ISO 281 kappa-factor relationship; see TriboNet’s rolling-bearing lubrication and kappa-factor background.

Method and assumptions

The calculation follows the TriboNet bearing lubrication context: kappa = nu / nu1. The kappa factor is one input into lubricant selection, not the whole bearing-life decision.

Stle
  • Use operating-temperature viscosity, not only ISO VG viscosity at 40 C.
  • Determine reference viscosity from bearing manufacturer guidance, ISO 281 workflow, or another validated bearing calculation.
  • Check contamination, grease behavior, additive chemistry, water, vibration, misalignment, and electrical damage separately.
